|Model||Puncture cone External Diam. (mm)||Sleeve internal Diam. (mm)||Sleeve length (mm)||Puncture tube length (mm)||Puncture cone length (mm)|
|RYTC – 5/65||5.6||6||65||105||125|
|RYTC – 10/65||10.3||10.5||135|
|RYTC – 12/65||12.6||13|
|RYTC – 15/65||15.4||15.7|
|RYTC – 5/100||5.6||6||97||140||174|
|RYTC – 10/100||10.3||10.5||98||183|
|RYTC – 12/100||12.6||13||100||180|
|RYTC – 15/100||15.4||15.7||111||160||203|
1. Good performance of dynamic sealing. It can bear pressure is greater than 37 mmHg, clinical required 8~15mmHg;
2. Resistance of plugging and pulling is very small. Dynamic test data is less than 3.2N/mm, similar imported brands less than 3.2N/mm;
3. Drag reduction structure of plum membrane flap valve, lower resistance of plugging and pulling;
4. Puncture cone head has cutting edge with six-sided knife type blade;
5. Puncture cone universal orientation, without directional insertion.
